4 Wide 6 Bit Binary Decoder

DCdecodersDC002Archived Feb 07, 2026

✅Functional

Authors:dzreams

View

This decoder takes six bits and outputs a pulse at one of 64 slices corresponding to the code. It's 4 wide.

Features

• Constant time decoding. 14gt latency.
• Slim profile. 4 blocks wide.
• 6gt throughput.
• QC based logic.
