Dual Sided 6 Bit Binary Decoder

DCdecodersDC005Archived Feb 07, 2026

✅Functional

Authors:floppydonkey

View

This decoder takes six bits and outputs a pulse at one of 64 slices corresponding to the code. The device is dual sided, meaning it can output a signal to one of two different sides. This effectively adds another bit to the decoder, allowing for 128 different outputs.

Features

• Dual sided outputs.
• Signal travels 100 blocks per second.
• No 1gt offset needed. This is achieved through a combination of TTP to get the proper update order, and some rail diodes.
• Minimal flashing rails. QC based logic with BUDed rails.
• Hopperspeed throughput.
